Heavy Load Drop Forged Link Chains

/onecol/cms/550/Schwerlastketten-Titel.jpg

The pictured tabs are an excerpt from our current range of Heavy Load Drop Forged Link Chains. We are constantly expanding our manufacturing program to include Heavy Load Chains.

At present the following divisions are available in different versions:

163 mm, 242 mm

/onecol/cms/549/Schwerlastketten-Produkt.jpg
/onecol/cms/551/Schwerlastketten-Bolzen.jpg

/onecol/cms/547/Schwerlastlaschenketten-2.jpg

Breaking loads

Heavy load drop/Pitch
Material C45
normally annealed
Material C45
hardened/tempered
Material 42CrMo4
hardened/tempered
163 x 70 x 47 mm
1015 KN
1350 KN
1860 KN
242 x 100 x 70 mm
2163 KN
2884 KN
3965 KN
